• Up to 300,000 per month
  • Flexible: Up to 11 feeders
  • Modular design
  • Widescreen touch control panel
  • Bar code, glossy, & large feeder options
  • Up to 80 sheets in flat envelope
  • Tower Feeder with 5 configurations available
Photos of the folds performed by Formax FD 7200 folder/envelope inserter

Get a
Item #: Formax-7700
Availability: Call or Email To Order
Price: CALL
Quantity:

    Formax 7700 Series Inserters offer the flexibility and power to process a wide variety of inserting jobs. The modular design includes up to 11 feed stations, high-capacity feeders, and a widescreen touchscreen interface. A robust folding system folds up to 8 sheets at a time, with the power to process up to 6,000 envelopes per hour, and up to 300,000 finished pieces per month.



    The top-loading envelope hopper holds up to 800 #10 envelopes or 500 flats, in landscape orientation.


    Inserting into landscape flats offers higher processing speeds, fewer jams, and lower envelope costs. The 7700 Series inserts sets of up to 80 pages, up to 10mm thick.


    Standard features include a high-capacity 4-foot outfeed conveyor, which can be used in-line or at a 90° angle, an accumulator/divert deck which holds up to 300 sheets, and custom cabinets for sturdy, movable storage.



    The 7700 Series color touchscreen interface is the new standard for all PC-driven inserters. With graphics based on a photo-image of the inserter, it also provides the ability to edit documents while creating jobs. This new interface, combined with unlimited programmable jobs, makes creating and running inserting jobs easier than ever before.



    All configurations include a Tower Feeder, which uses twin scanners to read codes either face-up or face-down. The 7700 Series has the ability to read 1 and 2-track OMR, 1D barcodes, and 2D Data Matrix, with codes located anywhere on the page.

    In addition, infrared and electromechanical double document detectors ensure the correct documents get into each envelope. Optional high-capacity feeders are available with or without intelligence, and can insert various media, including glossy booklets, DVDs and small inserts up to 6mm thick.

    The 7700 is the most flexible and robust folder inserter on the market. Please call us to explore its many possibilities.
